G3 Subminiature Sealed Micro Switch Information
Unionwell G3 series switch is a kind of subminiature waterproof micro switch and with IP67 function. So most the designer will use them to resist a wet environment, such as tap, automotive accessories, electric toothbrush, Electric-drive airer, Shared umbrella, waterproof power bank, vacuum cleaner, and so on. In summary, the G3 Subminiature Sealed Micro Switch is widely used in automobile parts and household appliances.
Meanwhile, in order to meet different installing requirements, there have various items for options. For example, you need a switch can install M3 screw, we will provide the item to you. And if you need PCB terminals type, it is also available too so any item you need, any item we can provide.
G3 Subminiature Sealed Micro Switch Parameters
| Rating | 0.1A, 125/250VAC; 3A/12VDC; 0.1A/48VDC; μ 1E5 | |
| Operating Frequency | Electrical | 0.1A, 120 cycles/min 3A, 10~30 cycles/min |
| Mechanical | 120 cycles/min | |
| Contact Resistance (Initiative) | 100mΩ Max.(without wire type) | |
| Insulation Resistance (at 500VDC) | 100MΩ Min. | |
| Vibration Durability | 10~55Hz, move 0.75mm (p-p) | |
| Dielectric Strength | 500VAC (50~60Hz) | |
| Operating Temperature | -40℃~+85℃ | |
| Operating Humidity | 85%RH Max. | |
| Service Life | Electrical | Min. 100,000 cycles (Depend on part NO.) |
| Mechanical | Min. 500.000 cycles | |
G3 Subminiature Sealed Micro Switch Parameters
These are our G3 series microswitch for sale and options, and because of too many models, some of them are not displayed on the website, welcome to contact us to have more product information.
