Subminiature Micro Switch(G10B)-Subminiature Microswitch Lever On/Off Switch
| Place Of Origin | Guangdong, China (Mainland) |
| Brand Name | Unionwell |
| Model Number | G10A03-150S03CU |
| Electrical Rating | ENEC/CQC 3A 125/250VAC 30VDC, 1E4 μ 40T85UL/cUL 3A 125/250VAC 30VDC |
| Operating Force | 150gf Max |
| Terminal Style | Solder terminals |
| Lever Type | 03# lever |
| Circuit Code | SPST-NO |
The Features Of Subminiature Microswitch Lever
- Small compact size
- Long life and high reliability
- Variety of levers optional
- Various of terminals
- Custom micro switch design and engineering solutions for your applications
- Widely used in appliances and industry control
The Parameters Of Subminiature Microswitch Lever
| Rating | P1 | 0.1A 125/250VAC 30VDC |
| 03 | 3A 125/250VAC 30VDC | |
| Operating Frequency | Electrical | 10~30 Â cycles/minute |
| Mechanical | 120 cycles/minute | |
| Contact Resistance(initial value) | 100mΩ Max (without wire type) | |
| Insulation Resistance | at 500VDC,100MΩ Min. | |
| Dielectric Strength | AC 600VAC RMS (50-60HZ) | |
| Storage Temperature | -40°C~+85°C | |
| Storage Humidity | 85%RH Max | |
| Service Life | Electrical | 10,000 cycles |
| Mechanical | 1,000,000 cycles | |
Our Advantage
Packing
Shipping
FAQ
Q1. Could you accept OEM or ODM?
A: Yes, we have a strong R&D team. We have rich experience in OEM&ODM.
Q2. Do you have micro switch patents?
A: Yes, we have more than 200 micro switch patents.
Q3. How many employees are in your factory?
A: There are over 600 employees at present in our factory.
Q4. How many engineers are in your R&D department?
A: Around 60 engineers in the R&D department, half of them own more than 20 years of micro switch experience.
Q5. What’s the capacity per month?
A: Over 8 million pieces per month for the micro switch series.
Over 20 million pieces per month for the keyboard switch series.
