Air Wind Pressure Switch For Water Heater Boiler

Place Of Origin Guangdong, China (Mainland)
Brand Name Unionwell
Model Number GPS100-80-100CC-2CPGLU
Electrical Rating ≥0.1 And ≤5A
Terminal Style 6.3×0.8mm 250# Quick Connect Terminals
Circuit Code SPST-NO
Color Of Micro Switch Gray
Pressure Type Negative Pressure
Contact Us
[google-translator]

The Specifications Of Air Wind Pressure Switch For Water Heater Boiler

  1. Set point range:10-1500Pa
  2. Operating pressure range：25-1500Pa
  3. Switching pressure range：10Pa Min
  4. Fixed set-point calibrated in the factory
  5. Maximum pressure allowed: 4000Pa
  6. Switch rating: 0.1A 125/250VAC, 3A 125/250VAC, 5A 125/250VAC, 16A 125/250VAC
  7. Circuit configuration:  SPDT, SPST-NO, SPST-NC
  8. Measured media: Air
  9. Operating temperature: -40℃~+90℃
Arcade Microswitch

Our Advantage

Arcade Microswitch

Packing

Arcade Microswitch

Shipping

Arcade Microswitch

FAQ

Q1. Could you accept OEM or ODM?
A: Yes, we have a strong R&D team. We have rich experience in OEM&ODM.

Q2. Do you have micro switch patents?
A: Yes, we have more than 200 micro switch patents.

Q3. How many employees are in your factory?
A: There are over 600 employees at present in our factory.

Q4. How many engineers are in your R&D department?
A: Around 60 engineers in the R&D department, half of them own more than 20 years of micro switch experience.

Q5. What’s the capacity per month?
A: Over 8 million pieces per month for the micro switch series.
Over 20 million pieces per month for the keyboard switch series.
